CAPACITY 1000 KG TO 3000 KG-
Conforming to ISS-500 (Revised) A reliable solution for your lifting & shifting problem by our firms, pioneered in manufacturing Material Handling Equipments since 1976.
USES:— Industries, Storage, Harbours, Docks, Railways, Warehouses etc.
ADVANTAGES: —
1. Its Construction is strong & Robust with the correct weight/capacity ratio. 2 The lowering lever is mounted on the steering handle to give easy operation.
3. Hydraulic system is leak proof and incorporates valves, cylinder, reservoir & overload safety device. The Ram is of hardened chromium plates.
4. The spring pressure keep the handle in the verticle position.
5. Grey Iron casting wheels fitted with double bearings in each wheel for smooth movement.
6. A pressure relief valve is fitted to prevent overloading.
7. Control — By pump from steering handle, gives high leverage for fast & easy lifting, makes 180 side turning very smoothly.
Dimensions in MM ( Subject to change without notice )
Capacity in KG
Fork Span
Fork Lenght
Fork Height WIN
Fork Height MAX
Fork Width
1000
520
1100
80
200
125
2000
520
1100
80
200
125
3000
520
1150
100
200
200
